- Working Temperature: -40°C ~ +105°C for industry, -55°C ~ +125°C for military
- Working Frequency: 50 kHz ~ 500 kHz
- Packaging size: 8.5mmx7.9mmx5.5mm max
- Max current: 10A
- Application: switching power supply
Current in A | Winding Ratio | Inductance of Secondary in µH | Resistance of Primary in mΩ | Resistance of Secondary in mΩ |
10
|
1:50 | 0.5 | 0.8 | 850 |
1:70 | 1.1 | 0.8 | 2000 | |
1:100 | 2.0 | 0.8 | 5800 | |
1:125 | 3.5 | 0.8 | 6900 |
